Claudian WeChat Bridge

中文 | English

Remote control your Claudian AI coding agent inside Obsidian directly from WeChat, via the official WeChat ClawBot (iLink) interface.

WeChat messages and images are relayed into a live Claudian session, and Claudian's responses are relayed straight back to the same WeChat conversation — turning your WeChat chat into a portable remote controller for your Obsidian agent.

Overview

Claudian embeds Claude Code (and other coding agents) as a sidebar inside Obsidian. WeChat ClawBot is an official WeChat capability that lets a bot account exchange messages with WeChat users over a long-polling HTTP API. This project connects the two seamlessly.

Shipped as a single self-contained Obsidian plugin folder:

• obsidian-plugin/ — Obsidian plugin (claudian-wechat) running inside Obsidian alongside Claudian. It exposes a local loopback HTTP interface and drives Claudian's own chat tabs and runtime objects.
• obsidian-plugin/relay.py — Bundled Python script managing the WeChat ClawBot protocol (QR login, long-poll getUpdates, sendMessage) and forwarding data between WeChat and the plugin's local HTTP endpoint.

The plugin manages relay.py's entire lifecycle automatically: it locates your system Python, bootstraps an isolated virtual environment (venv/, created only on first run), installs dependencies, presents an in-Obsidian QR code modal for initial WeChat login, and spawns relay.py serve as a managed child process. When the plugin is disabled or Obsidian is closed, the relay exits cleanly.

All communications between the plugin and relay stay strictly on 127.0.0.1.

Architecture

WeChat User (Mobile)
    |
    v
WeChat ClawBot (Official Tencent Server)
    |  iLink API: QR login, long-poll getUpdates, sendMessage
    v
relay.py                                    (bundled with plugin, managed as child process)
    |  HTTP POST 127.0.0.1:39217/message     (loopback only)
    v
obsidian-plugin (claudian-wechat)            (TypeScript, running in Obsidian)
    |  interacts with loaded Claudian plugin runtime
    v
Claudian (github.com/YishenTu/claudian)      (driven via runtime objects)
    |
    v
Claude Code / Configured Provider

Features

• Zero-Config Bootstrap: Automatically creates a dedicated Python virtual environment, prompts QR login inside Obsidian, and manages background relay processes.
• Two-Way Streaming: Send text and images from WeChat into Claudian; receive responses and status updates back in real time.
• Multi-Image Batching: Send multiple photos in sequence with cached buffering; append a follow-up caption to send together, or use /skip to send buffered images immediately.
• Mid-Send Tab Switch Protection: Automatically tracks and verifies target conversation IDs before and during message dispatch to prevent sending to the wrong tab or losing responses.
• Remote Session Management:
  • /ls — List known Claudian sessions sorted by update time
  • /goto N — Switch to session #N
  • /new — Detach and start a fresh session on the next message
• Runtime Configuration Control: Switch /model (omit arguments to list available models), /effort (thinking level), and /permission (permission mode) from WeChat.
• Slash Commands Forwarding: Send /commands to discover Claude's native commands, vault commands, and skills; all slash commands can be executed straight from WeChat.
• Desktop Mirroring (/listen): Push desktop Claudian interactions to WeChat in real time.
• Noise Filtering: Cleans out internal tool calls, raw thinking traces, and subagent chatter, forwarding only final assistant text.
• Bilingual Interface: Full Chinese and English bilingual support, automatically matched to Claudian's configured locale.
• Token Usage Metric: Reports context window token consumption at the end of each completed turn.

Requirements

• Desktop Obsidian (isDesktopOnly, Windows / macOS / Linux).
• Claudian plugin installed, enabled, and configured with a working provider.
• WeChat account with official ClawBot access.
• Python 3.11+ available on system PATH.
• Node.js & npm (only required if building from source).

Installation

Method A: From Release (Recommended)

1. Download the latest release package from Releases.
2. Extract to <vault>/.obsidian/plugins/claudian-wechat/.
3. Enable Claudian WeChat Bridge in Obsidian Settings -> Community Plugins.
4. Open the Claudian sidebar once so the bridge can attach.

Method B: Build from Source

git clone https://github.com/xsvm/obsidian-claudian-wechat.git
cd obsidian-claudian-wechat/obsidian-plugin
npm install
npm run build

Copy the built files (manifest.json, main.js, relay.py, strings.json) into <vault>/.obsidian/plugins/claudian-wechat/ and enable the plugin.

Commands Reference

Command	Description
/help	Display command reference and usage
/ls	List known conversations, numbered
/goto N	Switch to conversation #N
/new	Start a brand new conversation
/model	List available models for the current provider (static list for claude, discovered models for others)
/model <name>	Change model (e.g. /model opus, /model sonnet)
/effort <level>	Change reasoning effort (e.g. /effort low, /effort high)
/permission <mode>	Change permission mode (e.g. /permission yolo, /permission default)
/status	View current model, effort, permission mode, and listen state
/hist	List input history in current session
/hist N	View the response corresponding to message #N
/skip	Immediately dispatch cached images without waiting for caption
/listen on / /listen off	Toggle live mirroring of desktop turns to WeChat
/commands	List Claude Code's native slash commands
any other text	Forwarded directly to Claudian as prompt

Design Principles

• Non-Invasive API Usage: Drives Claudian through its native methods (claudian.mutateSettings and InputController.sendMessage) rather than tampering with DOM elements or raw settings files.
• Local Isolation: HTTP server strictly binds to 127.0.0.1:39217 without external network exposure.
• Lifecycle Guarantees: relay.py child process is tightly managed by RelayManager to avoid orphaned background processes.

Acknowledgments

• Claudian by Yishen Tu — The core Obsidian agent plugin driven by this bridge.
• wechat-clawbot by nightsailer (Pan Fan) — Python WeChat ClawBot iLink API client foundation.
• The wider WeChat ClawBot ↔ Claude Code bridging community.

Community

Join the WeChat group for questions, feedback, and updates:

License

This project is licensed under the MIT License.
