Echo Notes

Echo Notes is a personal action capture and AI memory-building plugin for Obsidian. Starting from audio transcription, it turns meetings, ideas, study notes, interviews, and everyday thinking into Markdown text, then uses configurable AI analysis templates to turn raw voice into searchable, linkable, reviewable, and reusable personal knowledge assets.

The goal is not just to turn speech into text. Echo Notes is designed to help your actions, thoughts, and decisions continuously enter your personal knowledge system, so they can eventually become long-term context for a Personal Agent. Every recording captures a real moment of action; every transcript becomes a memory that AI can understand; every structured analysis adds experience to a future AI version of yourself.

The workflow is simple: insert or link an audio file in a Markdown note, run a transcription command, and Echo Notes creates a .transcript.md file and inserts a "view transcript" link back into the source note. If AI analysis is enabled, Echo Notes can choose an analysis template from nearby keywords and write structured analysis back into the matching transcript. The experimental Echo Memory workflow can then turn a transcript and its successful analyses into traceable meeting pages, candidate memories, and managed long-term profiles.

Privacy notice: Echo Notes makes network requests only when you start real-time transcription, transcribe an existing file, trigger AI analysis, or enable automatic Echo Memory extraction. Real-time mode continuously sends microphone PCM to Volcengine AgentPlan. Offline mode sends the selected audio to the configured offline provider. AI analysis sends final transcript text to the configured analysis provider. Memory extraction sends transcript text and the successful analyses selected for that run to a separately configured memory provider. Do not process content that should not be sent to external services.

Why Echo Notes

Different recordings need different analysis structures

Most transcription tools produce one generic text output, but different recording scenarios require different reading lenses.

• Work meetings care about decisions, action items, owners, due dates, risks, and open questions.
• Study notes care about core concepts, explanations, structured summaries, examples, and review checklists.
• Product requirement mining cares about user quotes, pain points, motivation, context, feature opportunities, and acceptance criteria.

Echo Notes uses configurable prompt templates so the same transcription workflow can produce documents that fit the actual scenario. You can use the built-in work minutes, study notes, product requirement mining, and role-based work templates, or define your own templates, recognition keywords, and prompts.

Meeting notes and transcripts should not live outside your knowledge base

Many meeting-minutes and transcription products can generate useful content, but the result often stays in a separate platform instead of becoming part of the Obsidian system you already use every day.

That creates several problems:

• Audio files, transcripts, and meeting notes are scattered across tools, making later lookup expensive.
• Transcripts are not automatically connected to daily notes, project notes, or related topic notes, so context is lost.
• Action items, decisions, and product signals from meetings do not naturally enter the existing knowledge workflow.
• During review, it is hard to move from one note back to the original recording, full transcript, and structured AI analysis.

Echo Notes keeps the original recording, full transcript, and AI analysis inside the current vault, with Markdown links back to the source note. Audio can then connect naturally with daily notes, projects, meetings, learning records, and requirement management.

Long-Term Vision: Capture Actions and Build an AI Version of Yourself

Echo Notes is not only an audio transcription plugin, and not only a meeting-minutes tool. Its deeper idea is that human thinking, actions, judgment, and reflection should be captured with as little friction as possible, then turned into personal context that AI can understand and use.

Traditional knowledge management usually records conclusions: a note, a document, a meeting summary, or a task list. But what truly shapes a person's ability is often not the isolated conclusion. It is the process behind it: why a judgment was made, what information was available, how people discussed the issue, which assumptions were raised, which actions were taken or abandoned, and whether the final result validated the original thinking.

These processes used to be difficult to preserve because they are scattered across meetings, voice memos, chats, temporary ideas, tasks, project execution, and retrospectives. Echo Notes starts from the most natural input: record the voice, transcribe it into text, structure the text, and let the result become Memory and Context that a personal AI can use over time.

From this perspective, each recording is more than a file. It is evidence of action. Each transcript is more than text. It is a captured thinking scene. Each AI analysis is more than a summary. It compresses human experience into reusable cognitive assets for the future.

Long term, Echo Notes aims to help users build a more complete AI version of themselves: one that knows which projects you worked on, which meetings you attended, and who you discussed problems with; one that understands how you judged requirements, decomposed problems, and made tradeoffs; one that learns your expression style, decision preferences, knowledge structure, and working methods. When a similar problem appears in the future, a Personal Agent can give advice based on your real history, not only generic knowledge.

The real goal is not to help you write a few fewer meeting notes. It is to continuously capture your real-world action trail and turn it into personal context infrastructure that future AI can understand, retrieve, reason over, and collaborate with. This direction should respect user control over data: personal memory should stay in your Obsidian vault whenever possible, and external providers should only be called when you explicitly configure and trigger them.

Features

• Choose Real-time transcription or Offline transcription above the Provider setting. Each mode keeps an isolated provider configuration.
• In real-time mode, Echo Notes captures the microphone independently, immediately creates a WebM recording and .transcript.md, and progressively writes provisional text, definite utterances, speakers, and time ranges.
• If AgentPlan fails, local recording continues and confirmed text is preserved. After stopping, Task Center offers an explicit Retry with offline provider action without automatically creating another paid request.
• Offline mode supports Alibaba Bailian, SiliconFlow, MOSI, Ollama, and LM Studio for audio files already stored in the vault.
• Transcribe the selected audio link in the current note.
• Scan and transcribe all supported audio links in the current note.
• Generate a Markdown transcript file with source metadata.
• Protect user edits and AI analysis during subsequent progress updates or retranscription by replacing only the Echo Notes managed transcript block. Existing legacy transcripts are backed up once before migration to the managed format.
• Insert a transcript link below the source audio reference.
• Skip reusable existing transcripts and insert missing transcript links; reuse requires matching source audio path, size, mtime, transcription provider, model, and status: done.
• Avoid transcript filename collisions in a custom output folder by adding a stable source-path hash to generated transcript filenames.
• Show the selected transcription provider's upload mode, endpoint shape, file limit, chunking, language, timestamp, and diarization capabilities in settings.
• Run a local transcription-provider configuration check for API key, Base URL, model, HTTP risk, endpoint shape, and capability-limit warnings without uploading audio.
• Standardize transcription provider errors and redact API keys, authorization headers, Base64 audio payloads, and overlong responses before showing or writing failure messages.
• Use a shared AudioChunkPipeline core for long-audio preparation, chunk progress events, segment transcription, text merging, trace id aggregation, raw segment collection, and releasing completed chunk audio buffers.
• Open an in-memory Task Center from the ribbon or command palette to inspect transcription, AI analysis, and memory extraction status, failures, durations, providers, models, and outputs. Memory extraction can be retried while running or after failure.
• Optional manual-upload confirmation that previews provider, base URL, model, file size, and HTTP risks before sending audio; automation skips uploads when this confirmation mode is enabled.
• Markdown-link automation skips source notes marked with Echo Notes privacy frontmatter or private tags.
• In offline mode, enable or disable Obsidian's core Audio recorder and save hotkeys for its commands. Real-time mode does not intercept or depend on the core recorder's private state.
• Analyze transcript Markdown files with a separate AI model using built-in general, learning, product, and role-based work templates.
• Run AI analysis in the background and write the result back into the matching transcript.
• Optionally redact common sensitive fields before sending transcript text to the AI analysis provider.
• Run a local AI analysis configuration check for API key, Base URL, HTTPS, and model before sending transcript text.
• Split long transcripts into configurable chunks, analyze each chunk in order, and run a final synthesis pass that deduplicates conclusions, actions, risks, and open questions.
• Manually choose an enabled AI analysis template for the currently open transcript.
• Automatically choose one or more AI analysis templates from source-note frontmatter, tags, or keywords found within three lines above or below the source audio link, with a configurable default template as fallback.
• Configure each analysis template with a role group, name, version, recognition keywords, system prompt, and template task.
• Record Dataview-friendly AI analysis metadata for each generated template result, including template id, template name, template version, provider, model, generated time, and trace id when available.
• Track AI analysis lifecycle in transcript frontmatter with analysis_status, scheduled template ids, pending/done/failed template ids, provider, model, timestamps, and the latest sanitized analysis error.
• Optionally initialize an Echo Memory workspace and extract evidence-backed candidate memories from a transcript plus the successful analyses included in that run.
• Keep memory Provider, API key, Base URL, model, and long-text settings isolated from transcription and AI analysis configuration. Memory extraction is disabled by default.
• Choose between meeting pages plus candidate packages, or automatic compilation into User, person, organization, and project profiles. Candidate packages remain the source of truth, while profiles update only Echo Memory managed blocks.
• Rebuild managed profiles from candidate packages without scanning the whole vault or overwriting user-authored content.
• Optional automation for newly added Markdown audio links.
• Optional automation for newly created audio files.
• Markdown audio-link automation deduplicates processed links in the current plugin session using source note, normalized audio path, raw link text, and occurrence order.

Providers

Real-time transcription:

• Volcengine AgentPlan, fixed to doubao-seed-asr-2.0 and the official bigmodel_async endpoint, with speaker diarization and utterance timestamps. It requires Obsidian desktop and a local filesystem vault.

Offline transcription providers:

• 阿里百炼（Alibaba Bailian） with qwen3-asr-flash
• 【免费】硅基流动（SiliconFlow） with official choices FunAudioLLM/SenseVoiceSmall and TeleAI/TeleSpeechASR, plus custom model IDs
• MOSI with selectable moss-transcribe plain transcription or moss-transcribe-diarize speaker diarization
• Ollama through its local OpenAI-compatible /audio/transcriptions endpoint
• LM Studio through its local OpenAI-compatible /audio/transcriptions endpoint

AgentPlan real-time transcription keeps its official bigmodel_async Base URL and model read-only. MOSI locks its official Base URL and derives its read-only model from the Speaker diarization toggle: enabled uses moss-transcribe-diarize, while disabled uses moss-transcribe. Other offline-provider defaults remain editable. The settings tab switches language, microphone, and offline-provider fields with the selected mode and shows the relevant endpoint, size, chunking, timestamp, and diarization capabilities.

The settings tab also includes a local "Check transcription configuration" action. It checks API key presence, Base URL format, example URLs, non-local HTTP risks, model hints, endpoint shape, and known capability limits. This check does not upload audio and does not call the provider.

AI analysis supports SiliconFlow, Alibaba Bailian, DeepSeek, Volcengine AgentPlan, Ollama, LM Studio, and a custom OpenAI-compatible endpoint, in that order. The global default remains Alibaba Bailian deepseek-v4-pro; SiliconFlow defaults to Qwen/Qwen3.5-4B. Selecting AgentPlan locks the Base URL to the plan-specific https://ark.cn-beijing.volces.com/api/plan/v3 endpoint and provides a model picker for the currently documented text models, including Doubao Seed 2.0 Mini/Lite/Pro, Doubao Seed Evolving, DeepSeek V4, MiniMax M2.7/M3, GLM-5.2, and Kimi K2.6/K2.7 Code/K3. Kimi K3 requires Medium or higher, and preview models may be rate-limited during peak traffic. AgentPlan analysis remains isolated from AgentPlan ASR configuration and secrets by purpose.

AgentPlan officially limits its text-generation and embedding benefits to AI-tool scenarios. Before enabling this integration, confirm that your Echo Notes usage complies with the current plan terms. Using the dedicated Base URL and API key outside permitted AI-tool scenarios may lead to subscription suspension or account restrictions.

Network and Data Use

Echo Notes makes network requests only when transcription, AI analysis, or Echo Memory extraction is triggered.

• SiliconFlow default endpoint: https://api.siliconflow.cn
• Alibaba Bailian default endpoint: https://dashscope.aliyuncs.com/compatible-mode/v1
• MOSI transcription endpoint: https://api.mosi.cn/v1/audio/transcriptions
• Volcengine AgentPlan real-time ASR endpoint: wss://openspeech.bytedance.com/api/v3/plan/sauc/bigmodel_async
• Volcengine AgentPlan analysis endpoint: https://ark.cn-beijing.volces.com/api/plan/v3
• Ollama transcription default endpoint: http://localhost:11434/v1
• LM Studio transcription default endpoint: http://localhost:1234/v1
• AI analysis default endpoint: https://dashscope.aliyuncs.com/compatible-mode/v1
• Other AI analysis endpoints use the Base URL configured for the selected analysis provider.
• Echo Memory uses the Base URL configured for its separate memory provider and calls the OpenAI-compatible /chat/completions endpoint.

Offline transcription sends the selected audio to the configured offline provider. With MOSI, Echo Notes uploads multipart audio to api.mosi.cn through a synchronous non-streaming request. Diarization is optional: enabled mode requests speaker segments and timestamps, while disabled mode requests plain text only. No temporary segment files are created in the vault.

Real-time mode does not create or convert a complete WAV first. Echo Notes runs two local paths in parallel: MediaRecorder appends WebM Opus chunks to the vault about once per second, while Web Audio continuously downmixes and resamples the microphone to 16 kHz, 16-bit, mono PCM and sends 200 ms packets over one authenticated optimized bidirectional AgentPlan WebSocket. The recording, transcript, audio embed, and transcript link are created as soon as the session starts. Confirmed second-pass utterances are written progressively; unconfirmed text stays in a temporary region. If AgentPlan disconnects, local recording continues and already persisted audio and text remain available.

Real-time AgentPlan and diarization-enabled MOSI speaker IDs distinguish voices but do not identify real names. MOSI speaker IDs remain local to each independently submitted segment. AI analysis reads only completed final transcript text; when AgentPlan analysis is selected, that text is sent to its plan-specific Chat API and consumes plan quota. Echo Memory sends the transcript body and successful analyses included in the run to the memory provider. Transcription, analysis, and memory API keys remain isolated by provider and purpose in Obsidian SecretStorage. Keys are not written to plugin settings, transcripts, candidate packages, or logs. Recordings, transcripts, AI analysis output, and Echo Memory files remain in the Obsidian vault.

If "Confirm before manual transcription upload" is enabled in settings, Echo Notes shows a confirmation dialog before manual transcription uploads. The dialog lists the provider, Base URL, model, file size, and HTTP risk warnings. Automation skips uploads while this confirmation mode is enabled so audio is not sent in the background without user confirmation.

If "Redact transcript before AI analysis" is enabled, Echo Notes masks common sensitive values only in the transcript text sent to the analysis provider. The local transcript file is not modified. The current redaction covers labeled customer/contact/company/address fields, email addresses, phone numbers, Chinese ID numbers, long numeric identifiers, amounts, and common Chinese address fragments.

Markdown-link automation also skips source notes marked with Echo Notes privacy flags. Add any of these frontmatter values to a sensitive note:

echo_notes_private: true
echo_notes_disable_automation: true
echo_notes_disable_auto_transcribe: true

You can also use tags such as #echo-notes-private, #echo-notes-no-auto, #echo-notes-disable-automation, or #echo-notes-disable-auto-transcribe. These flags only disable background Markdown-link automation; manual commands still work when you explicitly run them.

Supported Audio Formats

• mp3
• mp4
• mpeg
• mpga
• m4a
• ogg
• wav
• webm

Provider limits:

• Volcengine AgentPlan doubao-seed-asr-2.0: real-time mode is fixed to bigmodel_async and requires Obsidian desktop with a local filesystem vault. Speaker clustering and utterance timestamps are always enabled. A standard Ark API key is not interchangeable with the dedicated AgentPlan API key.
• SiliconFlow: each request must stay within both 50 MB and one hour. Exceeding either limit triggers local decoding into roughly 10-minute 16 kHz mono WAV segments, uploaded sequentially. If media metadata cannot be read, Echo Notes still applies the size rule and attempts the normal request.
• HTTP 500/502/503/504 responses use 1-second and 3-second backoff retries before falling back to chunking. A persistently failing chunk alone is bisected; 413 splits immediately, down to 60 seconds and at most four levels. Authentication, quota, rate-limit, and invalid-model errors are not split.
• Retries and smaller chunks can create extra provider requests, but Echo Notes never changes the selected provider, API key, or model. Completed chunks are not retransmitted; failures keep completed text, trace IDs, and the failed time range.
• See the SiliconFlow transcription API reference for the current limits and model list.
• Alibaba Bailian qwen3-asr-flash: local files are encoded as Base64 Data URLs. If the full file would exceed the 10 MB Base64 input limit, Echo Notes decodes the file locally, converts it to 16 kHz mono WAV segments, transcribes each segment in order, and writes completed segments back to the same transcript draft.
• MOSI: enabling Speaker diarization uses moss-transcribe-diarize, version moss-transcribe-diarize-20260325, and diarize=true; disabling it uses plain moss-transcribe with version moss-transcribe-v1 and omits diarize. Both modes use the documented synchronous, non-streaming multipart request. Files longer than three minutes are split locally into roughly three-minute WAV segments and written back progressively. HTTP 500/502/503/504 retries use one- and three-second delays; a persistent server failure, 413, or an explicit too-long/too-large response shrinks only the failing segment down to 30 seconds and at most four levels. MOSI does not publish a stable file-size limit. See the MOSI transcription API reference.
• Ollama and LM Studio: files over 25 MB are blocked before upload.

Capability matrix:

Provider family	Upload mode	Endpoint shape	Limit	Echo Notes chunking	Language parameter	Timestamp	Speaker diarization
Volcengine AgentPlan real-time doubao-seed-asr-2.0	microphone PCM over authenticated optimized bidirectional WebSocket	/api/v3/plan/sauc/bigmodel_async	desktop and local filesystem vault only	No; one live session	Chinese or auto	Yes, utterance level	Yes
Alibaba Bailian qwen3-asr-flash	Base64 Data URL	/chat/completions + input_audio	10 MB encoded input	Yes	Yes	No	No
SiliconFlow FunAudioLLM/SenseVoiceSmall / TeleAI/TeleSpeechASR / custom model	multipart	dedicated SiliconFlow endpoint	50 MB and one hour per request	Yes; ~10-minute chunks with adaptive shrinking	No	No	No
MOSI moss-transcribe / moss-transcribe-diarize	multipart	/v1/audio/transcriptions	Determined by MOSI	Yes; ~3-minute chunks with adaptive shrinking	No	Diarization mode only, segment level	Optional
Ollama and LM Studio	multipart	/audio/transcriptions	25 MB audio file	No	Yes	No	No

Long-audio chunking belongs to the offline path and currently applies to Alibaba Bailian qwen3-asr-flash, SiliconFlow official or custom transcription models, and MOSI. M4A, MP4, and WebM still require full local decoding and may hit device memory limits; Echo Notes does not install or invoke FFmpeg. A real-time AgentPlan session consumes microphone PCM directly: provisional text is coalesced about every 500 ms, while new definite utterances, stop, completion, and failure force a write. If AgentPlan fails, local recording continues; after stopping, Task Center offers an offline retry but does not upload automatically. Chunked MOSI transcripts retain headings such as ## Segment 01（00:00-03:00）; diarization-enabled MOSI speaker numbering restarts within each segment while timestamps remain absolute to the original audio. MOSI plain mode keeps the same segment headings but emits no speaker labels.

Default transcription language is sent only to providers that support a language parameter, such as Alibaba Bailian, Ollama, and LM Studio. AgentPlan speaker diarization supports Chinese or an omitted language; selecting another language while AgentPlan is active automatically switches it to auto. SiliconFlow and MOSI do not receive a language field from Echo Notes; those providers detect the audio language.

AgentPlan and diarization-enabled MOSI transcripts show speaker labels. MOSI exposes a separate Speaker diarization toggle; when it is disabled, the Speaker label style setting is hidden and the transcript contains plain text. When labels are enabled, the style setting selects either speaker-only labels or the default speaker-and-time form:

**Speaker 1 (00:00-00:12)**

Transcript text.

Configure a Transcription Mode

1. Open the Echo Notes settings tab.
2. Choose Real-time transcription or Offline transcription above Provider. New installs default to offline mode with Alibaba Bailian.
3. Real-time mode: enter the dedicated AgentPlan API key and choose language, speaker-label style, and microphone. The official Base URL and model are read-only. Microphone permission is requested only when refreshing devices or starting a session.
4. Offline mode: choose Alibaba Bailian, SiliconFlow, MOSI, Ollama, or LM Studio, then confirm the API key and available provider settings. MOSI's official Base URL is read-only; use Speaker diarization to switch its derived read-only model.
5. Choose the copy language for inserted links and generated template labels.

Real-time commands:

• Echo Notes: Start realtime transcription
• Echo Notes: Stop realtime transcription
• Echo Notes: Open active realtime transcript

The real-time ribbon is visible in real-time mode; while recording, clicking it stops the session. Switching notes does not move the session: files remain bound to the source note active at start.

Recommended defaults:

Provider	Base URL	Model	Default language
Volcengine AgentPlan (real-time)	wss://openspeech.bytedance.com/api/v3/plan/sauc/bigmodel_async	doubao-seed-asr-2.0	zh
阿里百炼（Alibaba Bailian）	https://dashscope.aliyuncs.com/compatible-mode/v1	qwen3-asr-flash	zh
【免费】硅基流动（SiliconFlow）	https://api.siliconflow.cn	FunAudioLLM/SenseVoiceSmall	auto
MOSI（可选说话人分离）	https://api.mosi.cn/v1	moss-transcribe-diarize by default; moss-transcribe when disabled	auto
Ollama	http://localhost:11434/v1	whisper-1	zh
LM Studio	http://localhost:1234/v1	whisper-1	zh

Configure the Obsidian Core Plugin Audio Recorder

Obsidian's Audio recorder core plugin is used only by the offline workflow: it saves a complete recording after stop, then Echo Notes transcribes that file with the offline provider. Real-time mode uses Echo Notes' own recorder because the core recorder exposes no stable public live-audio chunk API. The core-plugin controls appear in the offline settings section.

That section can save hotkeys directly to Obsidian's core Audio recorder commands. Echo Notes does not assign default hotkeys, so it will not override common actions such as Save or Undo:

Action	Command	Hotkey
Start the Obsidian core plugin audio recorder	audio-recorder:start	User configured
Stop the Obsidian core plugin audio recorder	audio-recorder:stop	User configured
Transcribe all audio files in the current note	Echo Notes: Transcribe all audio files in current note	User configured

Echo Notes no longer registers proxy commands for starting or stopping the core recorder. When you click Save, it updates Obsidian's hotkey settings for audio-recorder:start or audio-recorder:stop; if your Obsidian version does not expose the internal hotkey manager, configure those core commands manually in Obsidian Hotkeys.

Configure AI Analysis

1. Open the Echo Notes settings tab.
2. Enable AI analysis.
3. Choose SiliconFlow, Alibaba Bailian, DeepSeek, Volcengine AgentPlan, Ollama, LM Studio, or a custom OpenAI-compatible endpoint. Alibaba Bailian remains the default provider.
4. Alibaba Bailian defaults to https://dashscope.aliyuncs.com/compatible-mode/v1 and deepseek-v4-pro; SiliconFlow defaults to https://api.siliconflow.cn/v1 and Qwen/Qwen3.5-4B. AgentPlan locks its plan-specific Base URL to https://ark.cn-beijing.volces.com/api/plan/v3 and defaults to doubao-seed-2.0-lite; choose another supported plan model from the dropdown when needed.
5. Enter the separate analysis API key. AgentPlan requires its dedicated plan API key, and Echo Notes does not reuse or overwrite the real-time transcription key.
6. Run "Check analysis configuration" to validate the API key, Base URL, HTTPS, and model locally.
7. Keep long-text chunking enabled for large meetings or interviews. The default chunk size is 24,000 characters and can be adjusted between 4,000 and 100,000.
8. Optionally enable transcript redaction before AI analysis if the transcript may contain sensitive personal, customer, company, address, or amount fields.
9. Choose the default analysis template used when no keyword is found near the audio link.
10. Edit, enable, disable, restore, or add templates in the analysis template settings.

Built-in template groups:

• General scenarios: work minutes and study notes.
• Management and people: manager sync and HR/people minutes.
• Product and delivery: product requirement mining, product manager, and project manager minutes.
• Engineering: engineering/technical minutes.
• Customer and growth: sales, customer success, and operations minutes.
• Custom: user-created templates start here and can be assigned to any group.

The template manager uses a fixed category switcher and shows one group at a time. Switch groups by clicking or with the Left/Right Arrow, Home, and End keys. The selected group remains active when template changes redraw the settings page.

The v2 built-in prompts use role-specific Markdown structures while sharing a neutral evidence policy. They separate facts, decisions, suggestions, and inferences; do not invent owners, dates, budgets, metrics, priorities, or sales stages; and treat transcript content as untrusted data rather than instructions. Action-item templates use a consistent table with item, owner, due date, and acceptance signal/next step.

Custom templates support a role group, name, recognition keywords, system prompt, template task, and enabled switch. Enabled templates participate in keyword matching; disabled templates keep their configuration but are not used automatically. During migration, an untouched v1 built-in preset is upgraded to v2 while preserving its enabled state. Any built-in template whose editable content was changed remains untouched until you explicitly restore its default.

Configure Echo Memory MVP

Echo Memory is disabled by default. Open the Memory extraction stage in Echo Notes settings, then:

1. Choose a vault-relative memory root folder. The default is Echo Memory.
2. Run initialization and provide only a display name, current role, and recent goal. Initialization creates the workspace and enables memory extraction. The workspace language follows the UI language selected at initialization time.
3. Select a separate memory Provider, then configure its dedicated API key, Base URL, and model. Memory secrets are stored by Provider in Obsidian SecretStorage and are never reused from AI analysis.
4. Choose whether to create meeting pages and candidate packages only, or also compile managed User and entity profiles.
5. Keep long-text chunking enabled for large inputs. The default chunk size is 24,000 characters with a maximum of 20 chunks. The default profile threshold is 0.75.

The default Chinese workspace layout is:

Echo Memory/
|-- 00 首页.md
|-- 01 会议/
|-- 02 记忆候选/
|-- 03 实体/人物, 组织, 项目/
|-- 04 User/SOUL.md and 01-08 profile documents
`-- 99 系统/echo-memory.json and 运行日志/

Each candidate package contains a readable Markdown table and plugin-managed JSON. Its input fingerprint covers the transcript body, included analyses, schema and prompt versions, output language, initialized user, Provider, and model. Repeating the same input reuses the existing candidate without calling the model again. Profile compilation replaces only content between echo-memory:managed markers and preserves user-authored text outside those markers.

Memory extraction has a 15-minute limit shared by all chunks. Running and failed memory tasks can be retried from Task Center. Retry first aborts the current wait and waits for the old attempt to exit, so late responses cannot write candidate data. Timeout, failure, and retry events are written to the Echo Memory run log without storing API keys or full model responses.

Commands:

• Echo Notes: Initialize Echo Memory
• Echo Notes: Extract memory from current transcript
• Echo Notes: Open Echo Memory home
• Echo Notes: Rebuild memory profiles from candidates

The current MVP does not include external Agent CLIs, a vector database, cross-vault sync, or automatic calendar and note actions.

Usage

Transcribe selected audio

Select an audio reference in the current Markdown note:

![[Recording 20260531001942.m4a]]

Run the command Echo Notes: Transcribe selected audio.

Echo Notes resolves the audio file, calls the configured provider, creates a transcript, and inserts a transcript link below the audio reference.

If AI analysis is enabled, Echo Notes first checks the source note frontmatter for echo_notes_analysis_template, echo_notes_template, or analysis_template. The value can be one or more enabled template ids or template names, either as a comma-separated value, an inline YAML array, or a YAML list. If no enabled frontmatter template is found, Echo Notes checks frontmatter tags and inline #tags against enabled template ids, names, and recognition keywords. If no tag matches, Echo Notes reads the three lines above and below the audio link and selects every enabled template whose keyword appears in that context. After the transcript link is inserted, AI analysis runs in the background; when each model call returns, the result is written before the transcript section in the same .transcript.md file. If no keyword is found, Echo Notes uses the configured default template.

Transcribe all audio files in the current note

Add one or more audio links to a note:

![[Recording 20260531001942.m4a]]
![[Recording 20260531002010.m4a]]

Run the command Echo Notes: Transcribe all audio files in current note.

If AI analysis is enabled, each audio link is matched independently. Different recordings in the same note can use different templates, or multiple templates, by placing different keywords near each audio link.

AI analysis generation

AI analysis runs automatically after a transcript is created or reused. Echo Notes inserts the transcript link first and does not wait for the model response. If "skip existing transcript" is enabled, running the transcription command again reuses only a status: done transcript whose source audio path, size, mtime, provider, and model still match, then generates or updates AI analysis in the background.

Each AI analysis task has a 15-minute limit shared by chunk extraction and final synthesis. On timeout, Echo Notes marks the task as failed, preserves the error state in the transcript, and keeps the Task Center retry action available.

To run analysis manually, open a .transcript.md file and run Echo Notes: Analyze current transcript with selected template, then choose any enabled template.

Echo Notes writes AI analysis into a controlled block before the transcript section. Running the same template again replaces that template's existing result instead of stacking duplicates; different matched templates are appended inside the same AI analysis block.

Each generated analysis result starts with Dataview inline fields prefixed with echo_notes_analysis_. These fields make template id, template name, template version, provider, model, generated time, and trace id queryable without parsing the generated Markdown body.

Transcript frontmatter also records the current AI analysis lifecycle. While analysis is running, analysis_status is analysis_pending; once all scheduled templates finish, it becomes analysis_done, analysis_failed, or analysis_partial_failed. The frontmatter keeps analysis_template_ids, analysis_pending_template_ids, analysis_done_template_ids, and analysis_failed_template_ids so Dataview can find transcripts that still need review or retry.

Frontmatter template selection applies to the whole source note and has priority over tags and nearby keywords. Tags apply to the whole source note and have priority over nearby keywords. Keywords are matched only against the source note lines around the audio link, not against the transcript body. If multiple templates match the same context, Echo Notes runs all matching enabled templates in settings order.

Output Example

Input:

![[Recording 20260531001942.m4a]]

Output:

![[Recording 20260531001942.m4a]]
[[Recording 20260531001942/Recording 20260531001942.transcript|查看转写稿]]

Generated file:

Recording 20260531001942/Recording 20260531001942.transcript.md

Inline AI analysis example:

Original recording: ![[Recording 20260531001942.m4a]]
Source note: [[2026-06-05]]

<!-- echo-notes-analysis:start -->
# Analysis Recording 20260531001942

<!-- echo-notes-analysis-item:start work-minutes -->
## Work minutes

- [echo_notes_analysis_template_id:: work-minutes]
- [echo_notes_analysis_template_name:: Work minutes]
- [echo_notes_analysis_template_version:: 1]
- [echo_notes_analysis_provider:: aliyun-bailian]
- [echo_notes_analysis_model:: deepseek-v4-pro]
- [echo_notes_analysis_generated_at:: 2026-06-01T10:00:00.000Z]

_Generated at: 2026-06-01T10:00:00.000Z; Provider: aliyun-bailian; Model: deepseek-v4-pro_

### Summary

This is the generated analysis content.
<!-- echo-notes-analysis-item:end work-minutes -->
<!-- echo-notes-analysis:end -->

# Transcribed manuscript Recording 20260531001942

This is the full transcript text.

Transcript frontmatter after AI analysis may include:

analysis_status: "analysis_done"
analysis_template_ids: [work-minutes, study-notes]
analysis_done_template_ids: [work-minutes, study-notes]
analysis_provider: "aliyun-bailian"
analysis_model: "deepseek-v4-pro"
analysis_started_at: "2026-06-01T10:00:00.000Z"
analysis_updated_at: "2026-06-01T10:03:00.000Z"
analysis_completed_at: "2026-06-01T10:03:00.000Z"

Automation

Echo Notes can optionally watch for Markdown audio links and newly created audio files.

• Markdown audio links: after a Markdown file changes, Echo Notes waits briefly, scans supported audio references outside frontmatter, fenced code blocks, and HTML comments, transcribes missing transcripts, and inserts missing transcript links.
• New audio files: after Obsidian finishes loading the workspace, Echo Notes can transcribe newly created audio files without modifying any source note. Without source-note context, AI analysis uses the default template.
• Transcription-time analysis: when AI analysis is enabled, manual transcription commands choose a template automatically from nearby audio-link keywords and write AI analysis back into the transcript in the background.
• Private source notes: Markdown-link automation skips notes with echo_notes_private, echo_notes_disable_automation, echo_notes_disable_auto_transcribe, or Echo Notes private tags.

All automation options are disabled by default.

Future Directions

Echo Notes' long-term goal is to evolve from an audio transcription tool into a personal AI Memory Layer. Echo Memory MVP now validates the first transcript-to-candidate-to-profile path. Future work will explore:

• Structured extraction from notes, including tasks, requirements, risks, decisions, action items, acceptance criteria, and retrospective results.
• Batch analysis across multiple transcripts to produce project-level, topic-level, and timeline-level summaries.
• A searchable personal action database built from meetings, study sessions, interviews, ideas, and work communication.
• Long-term context for Personal Agents, so AI can assist decisions based on the user's real history.
• Broader local model support, so personal memory can stay inside the user's own vault whenever possible.
• Reviewed promotion and correction workflows for candidate memories and managed profiles.

Build

npm install
npm run lint
npm run typecheck
npm test
npm run build

Development requires Node.js 22 or newer.

Install for Local Testing

1. Use a dedicated test vault.
2. Copy or symlink this folder to .obsidian/plugins/echo-notes/.
3. Run npm install and npm run build.
4. Enable community plugins in Obsidian.
5. Enable Echo Notes.
6. Configure a provider API key.
7. Insert an audio link and run one of the Echo Notes commands.

Current Limitations

• Speaker diarization and timestamps are always available for Volcengine AgentPlan real-time transcription, and optional for MOSI offline transcription. They identify speaker numbers, not real names.
• Real-time transcription requires Obsidian desktop and a local filesystem vault.
• The first real-time release supports start and stop only, not pause/resume. A forced exit can lose at most the last short WebM chunk that had not yet been emitted.
• Word-level timestamps are not rendered.
• Universal large-file chunking across all providers is not supported yet. The shared AudioChunkPipeline currently covers Alibaba Bailian qwen3-asr-flash, SiliconFlow official or custom transcription models, and MOSI.
• Local Whisper is not supported.
• Long-text analysis uses sequential chunk extraction plus a final synthesis call. It increases model calls and cost, and does not yet resume from a partially completed chunk sequence after restart.
• Task Center is currently an in-memory status panel. Persistent queues, pause/cancel controls, and restart-safe resume are not supported yet.
• Echo Memory is an experimental MVP. It does not yet include a vector database, cross-vault sync, external Agent execution, or automatic calendar and note actions.

Contact and Feedback

For questions, feedback, or collaboration, contact the author on WeChat.

• WeChat ID: ccanbang
