Nexus Dashboard

Code-block driven MOC dashboard for Obsidian.

Install

1. Download main.js, manifest.json, and styles.css from the latest release
2. Create a folder nexus-dashboard in .obsidian/plugins/
3. Copy the three files into it
4. Enable the plugin in Settings > Community Plugins

Quick Start

Create a note with a nexus-dashboard code block:

```nexus-dashboard
```

You can configure default settings in Settings > Community Plugins > Nexus Dashboard.

Dashboard Components

ASCII header

An ASCII art banner at the top of your dashboard.

Properties: text, font, color, size, mobileSize, align

```nexus-dashboard
header:
  text: MY VAULT
  font: ANSI Shadow
  color: #8A5CF6
  size: 1.0
  mobileSize: 0.5
  align: center
```

Stats bar

Shows file/folder counts from selected folders.

Properties: show (true/false)

```nexus-dashboard
stats: true
```

Section

A card grid area.

Properties: columns (1–4)

```nexus-dashboard
section:
  columns: 2
```

Card

A navigation link inside a section.

Card entries start with - type: (big or mini). Each section must contain only one card type — the section picks a single grid (mini-grid or big-grid) based on the first card, mixing types forces all cards into the wrong layout.

Properties: type (big/mini), label, desc, path, icon, color, columns (1–4 on parent section)

Big cards:

```nexus-dashboard
section:
  columns: 2
  cards:
    - type: big
      label: Journal
      desc: Daily reflections
      path: MOC/Journal MOC.md
      icon: Journal
      color: #8A5CF6
```

Mini cards:

```nexus-dashboard
section:
  columns: 3
  cards:
    - type: mini
      label: Quick Link
      path: MOC/Book Notes MOC.md
      icon: Book
```

Divider

A horizontal separator between sections.

Properties: title, type (default, bold, subtle, gradient, dashed)

```nexus-dashboard
divider:
  type: bold
  title: Archive
```

Recently modified

Shows the N most recently modified notes.

```nexus-dashboard
recently: true
```

Graph links

Injects wiki links at the bottom for visual navigation.

Properties: showGraph, exclude (comma-separated folder names)

```nexus-dashboard
graph:
  showGraph: true
  exclude: Templates,Attachments
```

Search bar

A search input that filters vault notes.

Properties: show (true/false), default (vault/cards), placeholder

```nexus-dashboard
search:
  show: true
  default: vault
  placeholder: Search your vault...
```

Links

A grid of clickable external or internal links.

Properties: title, columns (1–4)

Link items start with - url:. Each item can have label, icon, and desc.

```nexus-dashboard
links:
  title: Quick Links
  columns: 3
  items:
    - url: https://obsidian.md
      label: Obsidian
      icon: Link
    - url: https://github.com
      label: GitHub
      icon: GitHub
    - url: MOC/Journal MOC.md
      label: Journal
      icon: Journal
```

Row

Places the next N sections side-by-side in columns. row: is a marker — the sections that follow it become the row's children.

Properties: columns (1–4, defaults to 2), proportion, align (top/center/stretch)

```nexus-dashboard
row:
  columns: 2
  proportion: 50/50
  - section:
      columns: 1
      cards:
        - type: big
          label: Left Panel
          path: MOC/Journal MOC.md
          icon: Journal
  - section:
      columns: 1
      cards:
        - type: big
          label: Right Panel
          path: MOC/Projects MOC.md
          icon: Project
```

Column

Vertical stacking layout — places sections one above another inside a row.

Properties: spacing, align (top/center/stretch)

```nexus-dashboard
row:
  columns: 2
  - column:
      - section:
          columns: 1
          cards:
            - type: big
              label: Top Section
              path: MOC/Journal MOC.md
              icon: Journal
      - section:
          columns: 1
          cards:
            - type: mini
              label: Bottom Section
              path: MOC/Projects MOC.md
              icon: Project
  - section:
      columns: 1
      cards:
        - type: big
          label: Right Side
          path: MOC/Knowledge MOC.md
          icon: Knowledge
```

Commands

Open Ctrl+P / Cmd+P and search:

• Open dashboard — opens the full dashboard view
• Insert Nexus Dashboard code block — inserts an empty code block
• Insert ASCII art block — inserts a header code block
• Render selection as ASCII art — wraps selected text in a header block

Settings

Open Settings > Community Plugins > Nexus Dashboard to configure:

• General — open on startup, stats config (folder + label), export/import settings JSON, reset to defaults
• Header — ASCII text, font picker, color, desktop size, mobile size, alignment, live preview
• Dashboard — grid columns, MOC card editor (drag-and-drop reorder, collapsible sections), graph toggle
• Components — row/column layout editor, vault lists, quick links

Development

npm install
npm run dev      # watch mode
npm run build    # production build

License

MIT
