Blueprint Viewer

English | 中文

Render UE Blueprint / Material graph text as interactive diagrams directly in your Obsidian notes.

Usage

Use a blueprint code block and paste the blueprint text copied from UE:

```blueprint
Begin Object Class=K2Node_VariableGet ...
...
End Object
```

Options

Set options on the first line inside the code block:

```blueprint
MyBlueprintName
<blueprint text>
```

Or with explicit key=value:

```blueprint
height=600 name=MyBlueprint
<blueprint text>
```

Option	Default	Description
height	643	Render area height (px)
name	auto	Name label shown next to the copy code button; if the first line is a plain word (not starting with Begin Object and not a key=value pair), it is used as the name

Interaction

Action	Description
Ctrl + scroll	Zoom
Left-drag	Pan canvas
Double-click node	Enter sub-graph (collapsed nodes)
Graph button	Return to top level
All button	Fit all nodes (wheel zoom will prompt to click Reset afterwards)
Reset button	Reset to 1:1
copy code	Copy blueprint text to clipboard

Copying Blueprint Text from UE

1. In the UE Blueprint editor, select nodes (or Ctrl+A to select all)
2. Ctrl+C to copy
3. Paste into a ```blueprint code block in Obsidian

Technical Notes

• Renderer is a modified version of BlueprintUE Self-Hosted Edition (MIT License)
• Packaged as a <blueprint-viewer> Web Component, compiled into an Obsidian plugin via esbuild
• Modifications: left-drag pan, translate3d GPU acceleration (fixes zoom lag), All fit-to-screen button, copy code, name label, All-mode wheel-zoom hint
• Desktop only (isDesktopOnly: true), mobile not supported

License & Attribution

Plugin License

This plugin is released under the MIT License — see LICENSE.

Third-Party Attribution

The rendering engine code comes from BlueprintUE Self-Hosted Edition:

• Rendering engine: BlueprintUE render.js (MIT)
• Stylesheet: BlueprintUE render.css (MIT)

Original project info:

• Project: BlueprintUE Self-Hosted Edition
• Repository: blueprintue/blueprintue-self-hosted-edition
• License: MIT License
• Copyright: © BlueprintUE Contributors

This plugin is built on top of the original with modifications (left-drag pan, translate3d GPU acceleration, All button, copy code, etc.), and retains the original copyright notice per MIT license terms.
